Stunning super light carbon mountain bike fork with carbon fiber steerer, carbon fiber tube stanchions and forged 6061 Al dropouts.

This fork is disc brake specific. For a V-brake compatible fork see CC-F0225 for carbon or CC-F0125 for Al.

For the carbon steerer use an expansion plug instead of a star nut. See CC-E03, CC-E04, CC-E05, CC-E06

To actually see a section of your carbon steerer on your finished bike, pair up your fork with a eXotic Matrix F series stem featuring a steerer tube cut-out window on the steerer clamp. With Matrix F (and Meta F) stems, the rider sees a small oval section (aprox 22mm x 14mm) of the steerer tube at the rear of the stem.

Uncut steerer length	265mm				Offset/Rake	42mm
Diameter of leg tubes	34mm				Width between dropouts	100mm
Width of fork brace	83mm				Crown to underside of brace	25mm

Options and weight: VIEW FORK SELECTOR

Recommended rider weight limit: 97.5kg (215lbs)

Bike Type	Wheel Size	Material	Brake Mounts	Steerer	Length	Geom' Corrected for	Weight	Code	Features
MTB	26 in	Carbon (3K)	IS Disc	1.1/8 in Carbon	44.5cm	100mm	0.74Kg (1.6 Lbs)	CC-F0645
see full table

Product Code: CC-F0645
UPC: 5055429907855
